Description

A great choice to upgrade your RTR steering servo.

SPECIFICATIONS:

  • High Torque Digital Coreless Servo
  • SUBMARINE WATERPROOF: 7 Point Seals
  • Magnetic Angle Sensor
  • Pulse Width Modulation Control
  • Fully Programmable w/ REEFS Software (REEFS LINK required)
  • Voltage: 4.8V - 8.4V
  • Internal: Steel Gears / All CNC Aluminum Casing
  • Bearing Type: 3 Ball Bearings / Weight: 2.85oz
  • Dimensions: 1.57 x .78 x 1.5 (LWH)
  • Torque: 360oz (25.9kg)@ 6v/ 400oz (28.8kg)@7.4v/ 434oz (31.3kg)@8.4v
  • Speed: .13sec @6v/.11sec @7.4v/.10sec @8.4v
  • Spline: 25T
  • Dead Band Width: 2¦Ìs
  • BEC Not Required (Recommended for best performance)

UnloadCurrent

280mA@4.8V
 350mA@6.0V
 400mA@7.4V
 450mA@8.4V

LoadingCurrent

3000mA@4.8V
 3300mA@6.0V
 3800mA@7.4V
 4200mA@8.4V

For programming, the USB Link is required.

Item# REEFS65

Read More
Product Information
Vendor: REEFS RC
SKU: REEFS65
Availability: In Stock
Product Type: Car Electronics
Weight: 0.13 lb
